Bedrunka+Hirth 02.140V
back to Others

Stock number:
Control unit:
Delivery time:
Item location:
Item location - Cologne Cologne

Description of Bedrunka+Hirth 02.140V

CNC drawer cabinet for clear and clean tool storage.

The sturdy CNC drawer cabinet is a tool cabinet with 4 drawer slots for the safe and clean storage of drilling tools on the CNC drilling machine. Your high-quality tools are always ready to hand and neatly stored for use on the machine. The drawer cabinet consists of a welded sheet steel construction. The cabinet housing, measuring 705 x 736 x 1019 mm, is powder-coated and available in various RAL colors. The 4 drawers are galvanized and have a load capacity of 100 kg for the 3 upper drawers and 180 kg for the lower drawer.
All drawers are equipped with a self-closing mechanism, which ensures smooth and convenient operation.

Scope of delivery CNC drawer cabinet

  • One drawer with inserts type SK 40
  • Drawer division is made according to the 500 series with different heights (50/75/100/200 mm)
  • One oil-resistant corrugated rubber insert with dimensions 450 x 600 mm
  • The drawer division for the two upper drawers with a height of 100 mm consists of a middle compartment (600 x 75 mm)
  • For the drawer division with a height of 200 mm there is a middle compartment (600 x 175 mm)
  • CNC table top frame with 2 shelves with 10 SK 40 type inserts and an aluminum mounting block

Scope of delivery Welded sheet steel construction, powder-coated housing, galvanized drawers with individual pull-out stop and individual locking per drawer. Cylinder lock with central locking, handle strips with labeling strips.

Delivery without tools.

  • : 736 mm
  • : 705 mm
  • : 1019 mm
  • : Stahlblech
  • : 4
  • : 2x100, 1x300, 1x400
  • : 600 x 600 mm
  • : 127,57 kg
  • : 1500 kg
Please note the changing performance characteristics in different model years due to innovations. We therefore assume no liability or guarantee for the topicality, correctness and completeness of the information and technical data provided on this website.
